P P Rope
Dunline rope
P P Dunline Rope
Characteristics:
Long lasting – stabilized for exposure to Ultra Violet Rays
Excellent Strength
Non Corrosive
Greater abrasion resistance
Light Weight
Controlled elongation
Immunity to extreme atmospheric conditions
No water absorption – resistance to rot, mildew & marine organisms
Excellent shock absorption capacity
Inert to Chemicals
|
SIZE (DIAMETER)
|
WEIGHT
|
MINIMUM BREAKING STRENGTH
|
|||
|
mm
|
Inch
|
Lbs/100 ft
|
Kgs/100 mts
|
Kgs
|
Lbs
|
|
4
|
5/32″
|
0.50
|
0.74
|
280
|
472
|
|
6
|
1/4″
|
1.14
|
1.70
|
680
|
1327
|
|
8
|
5/16″
|
2.02
|
3.00
|
1200
|
2337
|
|
10
|
3/8″
|
3.06
|
4.55
|
1800
|
3439
|
|
12
|
1/2″
|
4.43
|
6.59
|
2700
|
4872
|
|
14
|
9/16″
|
6.05
|
9.00
|
3600
|
6724
|
|
16
|
5/8″
|
7.79
|
11.59
|
4500
|
8311
|
|
18
|
3/4″
|
9.95
|
14.80
|
5800
|
10604
|
|
20
|
13/16″
|
12.10
|
18.00
|
6900
|
12787
|
|
24
|
1″
|
23.85
|
35.50
|
9900
|
23589
|
|
28
|
1-1/8″
|
23.85
|
40.46
|
13200
|
26940
|
|
32
|
1-5/16″
|
30.91
|
46.00
|
16800
|
29762
|
4 Strand ropes are available from 6 mm dia onwards.
Tolerance:
up to 14 mm = + / – 8% » 16mm & above = + / – 5%
Coil Lengths:
These ropes are available in 100/200/300 mtrs or yards or 300 / 600 / 1200 ft. (Long lengths are available on request.)
Colours:
Aqua Green, Yellow, White & Blue are all available with or without a tracer yarn
About Rope:
Coils are available in standard lengths of 100mtrs, 220 mtrs, 330mtrs, or as required by the customer. Specific package size, length and weight can be prepared according to customers demand.
Useful for :
Transportation, Marine, Shipping, Fishing and specially made for SUBMERSIBLE PUMP INSTALLATION, useful for agriculture.
Size:2, 3, 4, 5, 6, 8, 10, 12, 14, 16, 18, 20, 22, 24, 26 ,28 mm
Characteristics:
- High ultra-violet light resistance
- Anti-abrasion
- Stronger than Royal PP Mono Ropes
- Cost effective & High strength
- Better breaking strength than Aquatuf
Applications 3 Strand :
- Fishing & Marine (Aquaculture & Fish farming)
- Industrial
- Rigging & Used in oil fields
PP ROPE
Polypropylene(PP) ropes are popular for their versatility, cost, strength and colour. The ropes are widely used in cytology, water sports (for their ability to float on the water), gardens, boating and yachting. Climbing and safety nets are made from these ropes.
Polypropylene Ropes can be provided in a wide range, which is lighter by nature and UV stabilized. It can be customized as per your requirement and can be provided in different sizes, types and colours
|
SIZE (DIAMETER)
|
WEIGHT
|
MINIMUM BREAKING STRENGTH
|
|||
|
mm
|
Inch
|
Lbs/100 ft
|
Kgs/100 mts
|
Kgs
|
Lbs
|
|
4
|
5/32″
|
0.50
|
0.74
|
214
|
472
|
|
6
|
1/4″
|
1.14
|
1.70
|
602
|
1327
|
|
8
|
5/16″
|
2.01
|
3.00
|
1060
|
2337
|
|
10
|
3/8″
|
3.05
|
4.55
|
1560
|
3439
|
|
12
|
1/2″
|
4.42
|
6.59
|
2210
|
4872
|
|
14
|
9/16″
|
6.04
|
9.00
|
3050
|
6724
|
|
16
|
5/8″
|
7.78
|
11.59
|
3770
|
8311
|
|
18
|
3/4″
|
9.93
|
14.80
|
4810
|
10604
|
|
20
|
13/16″
|
12.08
|
18.00
|
5800
|
12787
|
|
22
|
7/8″
|
17.45
|
26.00
|
8130
|
17923
|
|
24
|
1″
|
23.83
|
35.50
|
10700
|
23589
|
|
28
|
1-1/8″
|
27.15
|
40.46
|
12220
|
26940
|
|
32
|
1-5/16″
|
30.87
|
46.00
|
13500
|
29762
|
4 Strand ropes are available from 6 mm dia onwards.
Tolerance:
up to 14 mm = + / – 8% » 16mm & above = + / – 5%
Coil Lengths:
These ropes are available in 100/200/300 mtrs or yards or 300 / 600 / 1200 ft. (Long lengths are available on request.)
Colours:
Yellow, Blue, White are all available with or without a tracer yarn
HDPE rope
Product Specification
|
SIZE (DIAMETER)
|
WEIGHT
|
MINIMUM BREAKING STRENGTH
|
|||
|
mm
|
Inch
|
Lbs/100 ft
|
Kgs/100 mts
|
Kgs
|
Lbs
|
|
4
|
5/32″
|
0.54
|
0.81
|
200
|
441
|
|
6
|
1/4″
|
1.22
|
1.82
|
400
|
882
|
|
8
|
5/16″
|
2.20
|
3.27
|
700
|
1543
|
|
10
|
3/8″
|
3.29
|
4.90
|
1100
|
2425
|
|
12
|
1/2″
|
4.84
|
7.20
|
1500
|
3307
|
|
14
|
9/16″
|
6.38
|
9.50
|
2100
|
4630
|
|
16
|
5/8″
|
8.60
|
12.80
|
2800
|
6173
|
|
18
|
3/4″
|
10.82
|
16.10
|
3500
|
7716
|
|
20
|
13/16″
|
13.44
|
20.00
|
4300
|
9480
|
|
22
|
7/8″
|
16.33
|
24.30
|
5100
|
11244
|
|
24
|
1″
|
19.82
|
29.50
|
6100
|
13448
|
|
28
|
1.1/8″
|
26.41
|
39.30
|
8200
|
18078
|
|
32
|
1.5/16″
|
35.28
|
52.50
|
10700
|
23589
|
4 Strand ropes are available from 6 mm dia onwards
Tolerance:
Up to 14 mm = + / – 8% » 16mm & above = + / – 5%
Std Packing:
PE ropes are generally packed individually in plastic bags and then coils are packed in woven bags for shipping.
Coil Lengths:
These ropes are available in 100/200/300 mtrs or yards or 300 / 600 / 1200 ft. (Long lengths are available on request.)
Colours:
Yellow, Blue, Red, Green, Orange, White, Black. Brown.
Characteristics:
- Resistance to abrasion
- Shock loading
- Smooth finish
- Easy to handle
- Same breaking strength in dry or wet conditions
- Variety of colours
Applications 3 Strand :
- Commercial
- Marine & Fishing
- Domestics
- Trap fishing application
- Line haulers
Product Description
High-Density Polyethylene Rope (HDPE):
- 3-Strand “Z” Twist HDPE Mono-Multicolor Rope
- These ropes are manufactured with the help of virgin quality raw material under strict quality control for international standards. Extremely sophisticated automated machines and modern production techniques ensure that these ropes are highly flexible durable.
- HDPE ropes manufactured supplied by us are useful for all types of industries which include marine, fisheries, transport, shipping, utility power transmission, engineering construction etc.
(HDPE) are widely utilized for various applications like packaging, binding, producing fishing net and domestic purposes. Known for less water absorption, flexible, high durability.
